Protocol for Extraction and Purification of Genomic DNA from Blood (NEB #T3010)

Below is a detailed protocol containing explanations and commentary. If you prefer a more concise protocol, please use our Quick Protocol or download our Quick Protocol Card.


Before You Begin:

  • Store RNase A and Proteinase K at -20°C.
  • Add ethanol (≥ 95%) to the Monarch gDNA Wash Buffer concentrate as indicated on the bottle label.
  • Cold PBS (not supplied) is required for processing cultured cells.
  • Set a thermal mixer (e.g. ThermoMixer® or similar device), or a heating block to 56°C for sample lysis.
  • Set a heating block to 60°C. Preheat the appropriate volume of elution buffer to 60°C (35–100 μl per sample). Confirm the temperature, as temperatures are often lower than indicated on the device.
  • Do not load a single column with the lysed sample more than once; over-exposure of the matrix to the lysed sample can cause the membrane to expand and dislodge.

Genomic DNA Purification Consists of Two Stages:

PART 1: Sample Lysis

PART 2: Genomic DNA Binding and Elution



PART 1: SAMPLE LYSIS

Please follow the protocol specific to your starting material:

Mammalian Whole Blood (non-nucleated)

  1. Transfer 100 μl of whole blood to a 1.5 ml microfuge tube. If processing less than 100 μl of blood, add cold PBS to bring the total volume to 100 μl. For pre-aliquoted frozen samples, do not thaw; add Proteinase K, RNase A and Blood Lysis Buffer to the frozen sample in the following step.

  2. Add 10 μl Proteinase K, 3 μl RNase A and 100 μl of Blood Lysis Buffer to the sample and mix immediately by vortexing. For frozen samples, do not thaw; add enzymes and lysis buffer directly to frozen sample and proceed immediately to step 3. When working with multiple samples, prepare a master mix of the three reagents to save pipetting steps. Addition of RNase A can be omitted if a low percentage of copurified RNA will not affect downstream applications.

  3. Incubate for 5 minutes at 56°C in a thermal mixer with agitation at full speed (~1400 rpm). If an incubator with agitation is not available, use a heating block and vortex once or twice during the incubation. A longer incubation will not negatively affect the quality of the purified gDNA. For some hemoglobin-rich samples (e.g. horse blood), longer incubation times can be beneficial. Other hemoglobin-rich samples (e.g. guinea pig) can form green precipitates during this incubation that stain and clog the silica membrane. In such cases, lysis time should be shortened to 3 minutes.

  4. Proceed to Step 1 of Part 2: Genomic DNA Binding and Elution.

Nucleated Red Blood Cells (birds, reptiles)

  1. Transfer 10 μl of whole blood to a 1.5 ml microfuge tube.

  2. Add 90 μl cold PBS and mix by vortexing.

  3. Add 10 μl Proteinase K and 3 μl RNase A, and mix again by vortexing. Do not add the enzymes and the Blood Lysis Buffer simultaneously, as the high viscosity of the lysate will prevent equal distribution of the enzymes. Addition of RNase A is only necessary if a low percentage of co-purified RNA will affect downstream applications.

  4. Add 100 μl Blood Lysis Buffer and vortex thoroughly. The solution will rapidly become viscous.

  5. Incubate for 5 minutes at 56°C in a thermal mixer with agitation at full speed (~1400 rpm). If an incubator with agitation is not available, use a heating block and vortex once or twice during the incubation. A longer incubation will not negatively affect the quality of the purified gDNA.

  6. Proceed to Step 1 of Part 2: Genomic DNA Binding and Elution.



PART 2: GENOMIC DNA BINDING AND ELUTION

  1. Add 400 μl gDNA Binding Buffer to the sample and mix thoroughly by pulse-vortexing for 5-10 seconds. Thorough mixing is essential for optimal results.

  2. Transfer the lysate/binding buffer mix (~600 μl) to a gDNA Purification Column pre-inserted into a collection tube, without touching the upper column area. Proceed immediately to step 3. Do not reload the same column with more sample; over-exposure of the matrix to the lysed sample can cause the membrane to expand and dislodge. Avoid touching the upper column area with lysate/binding mix and avoid transferring foam that may have formed during lysis. Any material that touches the upper area of the column, including any foam, may lead to salt contamination in the eluate.

  3. Close the cap and centrifuge: first for 3 minutes at 1,000 x g to bind gDNA (no need to empty the collection tubes or remove from centrifuge) and then for 1 minute at maximum speed (> 12,000 x g) to clear the membrane. Discard the flow-through and the collection tube. For optimal results, ensure that the spin column is placed in the centrifuge in the same orientation at each spin step (for example, always with the hinge pointing to the outside of the centrifuge); ensuring the liquid follows the same path through the membrane for binding and elution can slightly improve yield and consistency.

  4. Transfer column to a new collection tube and add 500 μl gDNA Wash Buffer. Close the cap and invert a few times, so that the wash buffer reaches the cap. Centrifuge immediately for 1 minute at maximum speed (12,000 x g), and discard the flow through. The collection tube can be tapped on a paper towel to remove any residual buffer before reusing it in the next step. Inverting the spin column containing wash buffer prevents salt contamination in the eluate.

  5. Reinsert the column into the collection tube. Add 500 μl gDNA Wash Buffer and close the cap. Centrifuge immediately for 1 minute at maximum speed (>12,000 x g), then discard the collection tube and flow through.

  6. Place the gDNA Purification Column in a DNase-free 1.5 ml microfuge tube (not included). Add 35-100 μl preheated (60°C) gDNA Elution Buffer, close the cap and incubate at room temperature for 1 minute. Elution in 100 μl is recommended, but smaller volumes can be used and will result in more concentrated DNA but a reduced yield (20–25% reduction when using 35 μl). Eluting with preheated elution buffer will increase yields by ~20–40% and eliminates the need for a second elution. For applications in which a high DNA concentration is required, using a small elution volume and then eluting again with the eluate may increase yield (~10%). The elution buffer (10 mM Tris-Cl, pH 9.0, 0.1 mM EDTA) offers strong protection against enzymatic degradation and is optimal for long term storage of DNA. However, other low-salt buffers or nuclease-free water can be used if preferred. For more details on optimizing elution, please refer to “Considerations for Elution & Storage” in the product manual.

  7. Centrifuge for 1 minute at maximum speed (> 12,000 x g) to elute the gDNA.
